3D Visualization
The Gatan 3D Visualization Software enables the viewing and interpretation of reconstructed 3D volumes. It is strongly recommended that this software be run on a computer equipped with a high-end graphics card (NVidia or ATI) and at least 2 GB of RAM. Specific features are:
- Fully interactive and integrated with DigitalMicrograph
- Memory Efficient Volume rendering
- Memory Efficient Isosurface rendering
- Orthogonal slicing
- 3D line profiles
- 3D ROI specification and extraction
- Volume merging
- Simple Movie export (MPEG, AVI)
|
|
|
| Image of interplanetary dust particle; STEM tilt series acquired with a Gatan 806 HAADF detector from -61� to 68� by Dr. Ilke Arslan of Sandia National Laboratories, Livermore, California and Dr. John P. Bradley of Lawrence Livermore National Laboratory, Livermore, California; aligned, reconstructed and visualized using Gatan's 3D Reconstruction and 3D Visualization software; the iso-surfaces highlight two different intensity levels in the reconstruction. | Image of phosphorus-containing macromolecular assemblies in the cell nuclei of Drosophila larvae; dual-axis EFTEM tilt series acquired with a Gatan Tridiem energy filter from -66� to 66� by Dr. Maria Aronova and Dr. Richard Leapman, National Institutes of Health, Bethesda, Maryland; for each axis phosphorus L-23 series (20eV slit, pre-edge and post-edge) were collected; a jump ratio series was calculated and the data were aligned and reconstructed using IMOD (University of Boulder, Colorado); finally, the reconstruction was rendered in the Gatan 3D Visualization software; the inset highlights a sub-volume extracted using the 3D Visualization ROI tool. |
Product Requirements
| Product | System Requirements | Suggested Configuration |
| 3D Visualization |
|
>200 GB free hard drive space |
1 Recommended Graphics Cards include recent high-end display cards from NVIDIA and ATI. Contact Gatan to confirm compatibility.
